50CBM LPG Storage Tanks: High-Performance and Safety-Focused Solutions

50CBM LPG Storage Tanks: High-Performance and Safety-Focused Solutions

LPG storage tanks are essential stationary vessels designed to store Liquefied Petroleum Gas (LPG) and are widely utilized across various industries. Our company offers a range of LPG storage tanks with different capacities and standards, ensuring high safety performance and long durability. These tanks are engineered in compliance with the latest regulations, optimizing the structure to reduce material usage and enhance safety.

Key Features of Our LPG Storage Tanks:

1. Optimized Design: The tank's structure is meticulously designed to optimize performance based on its capacity, ensuring the best possible structure and minimizing material usage.

2. Enhanced Safety: The tightness between the valve and the flange is meticulously engineered to enhance safety performance.

3. Durable Pressure Gauge: The pressure gauge is connected via a flange, making it robust and less prone to damage during replacement.

4. Compliance with Standards: Designed and manufactured according to the AD 2000 standard (Markblatter).

5. Surface Treatment: Sandblasted to SA 2.5 and coated with epoxy paint with a minimum thickness of 250 microns.

6. Material Quality: Constructed from P 355 NH (WSTE 355) material.

7. Temperature Management: Equipped with a top sun shield and spring system to handle high temperatures.

8. Stress Relief: Heads are stress-relieved at 620°C.

9. Test Pressure: Tested at 25 bar.

Technical Specifications of the 50CBM LPG Storage Tank

Accessories for the LPG Storage Tank

1. Liquid Level Indicator:

• Type: UNZ-518C14

• Version: Magnetic type liquid level indicator

• Normal Pressure: 2.5 MPa

• Scope of Testing: 50-2300 mm

• Precision: 2.5

2. Safety Valve:

• Model: A42F-2.5-80

• Version: Built-in

• Normal Pressure: 2.5 MPa

• Normal Diameter: DN80

• Opening Pressure: 1.68-1.76 MPa

• Re-seating Pressure: More than 0.8 times the opening pressure

3. Loading and Unloading System:

• Feed Pipe: DN50

• Drain Pipe: DN50

• Admission Port: DN50

• Sewage Outfall Port: DN50

• Vent Nozzle Port: DN50

• Normal Diameter:

• Standard: GB150

4. Safety Fittings:

• Safety valve, column magnetic liquid level gauge, pressure gauge, thermometer, cut-off valves, etc.

Additional Specifications

• Designed Pressure: 1.66 MPa

• Filling Ratio: 0.42 kg/L

• Working Temperature: -50°C

• Corrosion Allowance: 1 mm

Equipped with one of the leading HNJS LPG tank brands, our company is a premier manufacturer and supplier of high-quality CE-certified LPG tanks. We invite you to wholesale our products directly from our factory and company, ensuring you receive top-tier quality and reliability.
